Four Wheels Underground Mining Truck 5 Ton

Shandong Beijun Heavy Industry Co., Ltd.
Contact Now

Four Wheels Underground Mining Truck 5 Ton

Brand Name : Beijun

Model Number : UQ-5

Certification : CE,ISO

Place of Origin : China

MOQ : 1

Payment Terms : L/C, T/T

Supply Ability : 1000 Set/Sets per Month

Delivery Time : 7 days

Packaging Details : Customized packaging

Engine Model : FAW - 4DW92-73

Engine Power : 54KW/73HP

Transmission Model : WANLIYANG 530

Drive Mode : 4x2

Dimension of Bottom Spring Plate : Length 70mm, Width 100mm

Loading Capacity : 5 Tons

Type of Bucket : U type Bucket

Thickness of Bucket Steel Plate : bottom 8mm side 6mm

Contact Now

Product parameters of Mini Underground Mining Dump Truck with Loading Capacity 1ton to 5 tons

Beijun underground tunnel dump truck is a specialized vehicle designed to operate effectively in underground environments. Its compact and agile design allows it to maneuver with ease in narrow spaces, while its enhanced safety features ensure that it can operate safely in hazardous conditions. The truck's robust performance enables it to transport heavy loads efficiently, while its durable construction ensures that it can withstand the harsh conditions of underground mining and construction operations.

One of the key advantages of the Beijun underground tunnel dump truck is its low maintenance and operating costs. Its advanced technology and efficient design reduce the need for frequent repairs and maintenance, making it a cost-effective choice for businesses and organizations. Overall, the Beijun underground tunnel dump truck offers a range of features and benefits that make it an ideal choice for a variety of tasks in narrow underground spaces, including its compact and agile design, enhanced safety features, robust performance, high bearing capacity and durability, and low maintenance and operating costs.

Model UQ-5
Engine Model FAW - 4DW92-73
Engine Power 54KW/73HP
Transmission Model WANLIYANG 530
Transmission Gear 5 Forward Gear, 1Back Gear,Rear High Speed Controller
Drive Mode 4x2
Front Axle Model 1069
Rear Axle Model 1069
Tire Model 700x16 Line Tire,
Rear Double Tyre One Side,
No.of Bottom Spring Plate Front 10 PCS, Rear 10 PCS, Spare 6PCS
Dimension of Bottom Spring Plate Length 70mm, Width 100mm
Size of the Bucket:Length×width×height U type Bucket 2800mm*1600mm*550mm
Type of Bucket
Thickness of Bucket Steel Plate bottom 8mm side 6mm
Unloading Type Hydraulic Double Top Dump
Steering Type Hydraulic power steering
Braking Type Air Brake
Cabin Canopy with Glass and Rain Bush
Driving Position Left Hand Drive
Cooling sytem Standard Water Cooling System
Loading Capacity 6 Tons

Four Wheels Underground Mining Truck 5 TonFour Wheels Underground Mining Truck 5 TonFour Wheels Underground Mining Truck 5 TonFour Wheels Underground Mining Truck 5 TonFour Wheels Underground Mining Truck 5 TonFour Wheels Underground Mining Truck 5 Ton
